OceanFlex Tinned Marine Battery Cable Red 120 sq.mm (~4/0 AWG)
OceanFlex Tinned Marine Battery Cable Red 120 sq.mm (~4/0 AWG) - 0.15m / Bare Ends (no terminals) is backordered and will ship as soon as it is back in stock.
Made-to-Order
Crimped In Accordance with BS7609
Marine-Grade
Tinned Copper Cable & Lugs
Description
Description
Custom-made 120mm2 Red Marine-Grade Tinned Battery Cable
We supply 120.0 sq. mm (~4/0 AWG) OceanFlex tinned cable, cut to the length you require with your choice of cable end terminals from:
- Bare ends (No connectors)
- M8 / 8.0mm hole diameter (marine-grade)
- M10/ 10.0mm hole diameter (marine-grade)
- M12/ 12.0mm hole diameter (marine grade)
- Any combination of the above
If you select connectors, we use high quality marine-grade Klauke tinned copper lugs with the cables crimped in accordance with BS7609, using the Klauke calibrated crimping system.
If you want an option not displayed, please get in touch with your requirements.
Custom-made Black 120mm2 battery cable is also available.
Specifications:
- 120mm2 Cable Conductor Cross-Section
- Conductor Specification (mm): 888/0.40
- Nominal Current Rating 600 Amps
- Maximum Overall Diameter: 19.6mm
- Tinned Copper Conductors in accordance with BS EN 60228:2005
- PVC Insulated - saves weight and offers good resistance to abrasion and cut through
- Suitable for use at temperatures from -30ºC to 70ºC
- Suitable for 12v and 24v systems (maximum 60v)
- Good resistance to petrol, diesel, lubricating oils and diluted acid
- Very good resistance to moisture
- Cables are printed with the specification on the insulation
Benefits of OceanFlex Cable:
- Marine-specific flexible cable
- Tinned thin wall low voltage wiring cable designed for use in harsh environments
- In OceanFlex cable, the copper strands are tin-plated so the cable is highly resistant to corrosion from sea water over long periods of time.
- Oceanflex cables have a much greater life span compared to standard cables.
- This leads to lower repair/maintenance costs and less down time due to electrical faults and failures.
If you need a cable length or specification not shown on our website, please contact us with your requirements.
